Nilfisk R Models

The CFM lateral trim vacuums, commonly known as the R Models, are used to extract trim (paper, plastic, fabric, etc.) from production lines. Suction power, construction features and dimensions are therefore tailored according to the production machines they need to serve.

The R models are available in five versions, from 0,85 to 4,0kW, with containers in 460 and 560mm diameter (total capacity of 114, 150 or 215 litre). The standard versions are equipped with a nylon liner filter; special liners are available for powder extraction. The suction unit, a three-phase continuous duty motor, is placed directly under the container. Thanks to the motor position, the liner is spread out and completely open and all product vacuumed in is neatly compacted on the bottom, optimising the container capacity. To empty simply open the lid and remove the liner. All the models are available in the painted and stainless steel AISI 304 versions. A 4 kW multi-stage blower in parallel connection is also available (model 3507W R). All the R models are ideal for automated applications (no need for the operator).

Nilfisk R155

Industrial vacuum for the collection of plastic, paper or textile trims. Its suction power, its features and its size make it the right vacuum to operate in packaging areas.

Model R 155 is equipped with a 1,1 kW three phase motor and a 150 litres container. It mounts a nylon filter, however specific filters for dust extraction are available. The three phase suction unit is placed under the container, the liner is spread out and completely open and all product vacuumed in is neatly compacted on the bottom, optimising the container capacity.

  • Small
  • No maintenance needed
  • Silent
  • Easy and quick disposal of waste material
  • High capacity
  • Quick visual level control: plexiglass port-hole in the lid
  • Specific liner filter for fine dust available
  • Stainless steel version

Specifications

Downloads

Accessory Boards Brochure
